odm PCB Printed Circuit Board Fabrication Manufacturing Low Volume Assembly

MOQ : 1

Price : Contact us

Payment Terms : T/T

Layer : 1-64 Layer

Base Material : FR4

Thickness : 0.5-10.0mm

Copper Thickness : 0.5-15OZ

Board Size : Customized

Min. Line Width/Space : 0.10/0.10mm

Surface Treatment : ENIG/Immersion Gold

Certificate : UL,IATF16949,ISO&Reach

Contact Now

Multilayer PCB Manufacturing Printed Circuit Board for Electronic Products with CE

♦ What's Multilayer PCB?

A Multilayer PCB (Printed Circuit Board) is a type of circuit board that consists of three or more conductive copper layers, laminated together with insulating (dielectric) material to form a single structure. These layers are interconnected through vias (plated holes), allowing complex circuitry in a compact space.

odm PCB Printed Circuit Board Fabrication Manufacturing Low Volume Assembly

♦ Key Features of Multilayer PCBs:

- Multiple Layers (typically 4, 6, 8, up to 50+ in advanced designs).
- Stacked Construction: Layers are bonded under heat and pressure.
- Inner Layers: Used for power/ground planes or signal routing.
- Vias: Plated holes (through-hole, blind, or buried) connect different layers.
- High Density: Supports complex circuits in a small footprint.

♦ Comparison with Single/Double-Layer PCBs:

Feature	Single-Layer	Double-Layer	Multilayer
Layers	1 (Top)	2 (Top + Bottom)	3+ (Multiple inner layers)
Complexity	Low	Medium	High
Cost	Low	Moderate	Higher
Use Case	Simple circuits	Moderate complexity	High-speed, dense designs

♦ Technical Parameters

Item	Specification
Laers	1~64
Board thickness	0.1mm-10.0mm
Material	FR-4,CEM-1/CEM-3,PI,High Tg,Rogers
Max panel size	32"×48"(800mm×1200mm)
Min hole size	0.075mm
Min line width	3mil(0.075mm)
Surface finish	OSP,HASL,Imm Gold/Nickel/Ag, Electric gold
Copper thickness	0.5-15 OZ
Soldermask	Green/Yellow/Black/White/Red/Blue
Silkscreen	Red/Yellow/Black/White
Min PAD	5mil(0.13mm)
Inter package	Vacuum
Outer package	Carton
Outline tolerance	±0.75mm
Hole tolerance	PTH:±0.05 NPTH:±0.025
Certificate	UL,ISO 9001,ISO14001,IATF16949
Special request	Blind hole+Gold finger + BGA
Material Suppilers	Shengyi, KB, Nanya, ITEQ,etc.
